Description
| Technical | |
| HDMI Compliance | HDMI 1.3 |
| HDCP Compliance | HDCP 1.3 |
| Video Bandwidth | 4.95 Gbps |
| Video Resolutions | up to 1080P@60Hz |
| Color Space | RGB, YCbCr 4:4:4, YCbCr 4:2:2 |
| Color Depth | 10-bit, 12-bit |
| Audio Formats | LPCM 2CH |
| ESD Protection | Human body model — ±8kV (air-gap discharge) & ±4kV (contact discharge) |
| Connections | |
| Inputs | 1x HDMI Type A [19-pin female] |
| Outputs | 1x RCA [Composite video] 2x RCA [Stereo audio] |
| Mechanical | |
| Housing | Plastic Enclosure |
| Dimensions | 66mm [W] x 55mm [D] x 20mm [H] |
| Net Weight | 40g |
| Power Supply | HDMI Source Powered |
| Power Consumption (Max) | 0.5W |
| Operation Temperature | 32 – 104°F / 0 – 40°C |
| Storage temperature | -4 – 140°F / -20 – 60°C |
| Relative Humidity | 20 – 90% RH (no condensation) |
